  • AC/DC pulses TIG/MMA Arc Welding Power Source--WSE-315(PNE30-315ADP)

AC/DC pulses TIG/MMA Arc Welding Power Source--WSE-315(PNE30-315ADP)

stars, based on ( 0 ) reviews
$2580.00now$2280.00 set
300 items available

    AC/DC pulses TIG/MMA Arc Welding Power Source


Feature code:
AC/DC pulses TIG/MMA Arc Welding Power Source
WSE-315(PNE30-315ADP)

Main characteristics:
● Easy arc ignition, low spatters and the non-caking to the work piece etc.
● Outstanding effectiveness in energy saving.
● With the modern single-chip computer control technology, the welder could be operated more easily.
● The welder could adjust to electrified wire netting more greatly and could work within a wide range of electrified wire netting limits.
● Foot controller function.
● Protective functions: overheat, over-current, under-voltage and power phase absence, etc.

Technical:

Model

WSE-315

WSE-500

Rated input voltage

3-380V±10%(50-60)Hz

Rated input power(kw)

12.1

17.6

No-load voltage(V)

67±6

76±6

Current adjusting range(A)

12~315

12~510

Slope up time (s)

0.1-10

Slope down time (s)

0.1-10

Spot welding time (s)

0.2-5

Pre-flow time (s)

0.1-1.5

Post-flow time (s)

1-15

Surge time range (MMA)

0.01-0.5s

AC frequency range(Hz)

20-100

AC balance

10%-50%

Duty cycle

100%

60%

Power factor(cosφ)

90%

Efficiency(η)

0.93

Insulation grade

F

Case protection grade

IP21S

Dimensions(mm)

700 x 360 x 780

Net weight(kg)

63

68
